Description
Certified to:
- FAA AC 70/7460-1
Compliant to:
- FCC Rules and Regulations
- Canadian Standards Association (CSA) PEC
FEATURES/BENEFITS:
- Meets FAA and FCC requirements
- Two 30A load contacts
- Maximum of 2,400W load per contact
- Surge protection
- LED power indicator
- Cast aluminum weatherproof box
- Solid-state circuitry for high reliability
- Light actuation: Energizes at 35 foot-candles | De-energizes at 60 foot-candles
- Each contact may directly switch a load, activate an OLA lighting contactor, or activate an OLC controller
- Operates on 60 or 50Hz frequency power
- Front housing hooks onto lower edge of the aluminum box for easy installation
- Screw terminals for 8 AWG wire
- Voltage tolerance + 20%
