Description
Compliances:
- FAA AC 150/5345-46: L-861 Series
- ICAO Annex 14
Features:
- ETL Certified (Blue only)
- Blue or Red glass globe for day light recognition
- Durable high impact sealing boot
- Single piece die-cast aluminum body
- Adjustable height
- Breakable coupling for stake, baseplate, or junction box mounting
- Constant current operation
- Available standard with 1.5 inch or optional 2 inch frangible coupling
- Long life LED
- Internally mounted, sealed, electronic power supply
- Direct replacement on existing baseplate
- Complies with the intensity curve requirements for 3-step or 5-step circuits, 50/60 Hz.
- Power Consumption – Lumen intensity steps powered by series circuit (6.6a/20a with proper isolation transformer)
- Non-Arctic Kit – Max fixture load 9.2W,11.2VA, PF=.82, Isolation transformer required 10/15 W
- Arctic Kit – Max fixture load 25.7W, 30VA, PF=.96, Isolation transformer required 30/45
